HE-Q670DB-RC

Support Intel® 15th/14th/13th/12th gen Core™ i9/i7/i5/i3 &

Pentium®/Celeron® processor, TDP 125W, LGA 1700

1 * DP: max resolution up to 4k@60Hz

1 * HDMI : max resolution up to4k@60Hz

1 * VGA: max resolution up to 1920x1200@60Hz

M.2_1: 1x M.2 M-Key2242/2280 Slot,Support PCIe 4.0 X4(NVMe) Mode

M.2_2: 1x M.2 M-Key2242/2280 Slot,Support PCIe 4.0 X4(NVMe)& SATA 3.0 Mode 4 * SATA

1* Intel® i219V, Co-lay with Intel® i219 LM;1* Intel® i210

1* Intel® i226V, Reserved

Realtek ALC897

1 * Mic in

1 * Line in

1 * Line out

2 * PCIe 5.0 X16 Slots (Support 1x 16 or 2x 8 mode)

2 * PCIe 4.0 X4 Slots

2 * PCIe 3.0 X4 Slots

1 * PCI Slot

2 * DB9 (RS232/422/485)

2 * RS232 (Header)

2 * RS232/ RS422/ RS485 (Header)

4 * USB3.2(TYPE-A, Rear IO)

2 * USB2.0 (TYPE-A, Rear IO)

2 * USB3.2(via (20-1) BOX header, Internal)

2 * USB2.0 (via (10-1)Pin Header, Internal)

8 * GPIO

1 * PS/2 Connector (Keyboard & Mouse)

1 * Front Panel Header (HDD LED+PWR LED+PWR ON+RESET)

1 * ESPI Header (Debug Only)

1 * SMBUS Header

3 * System FAN Header

1 * CPU FAN Header

1 * CMOS Clear Jumper

1 * AT or ATX Select Jumper

1 * ME Flash Header

1 * Power Monitor wafer

Windows 10 IoT Enterprise 2021 LTSC,Windows 10 (21H2),

Windows 11 (21H2) orlater,Linux Kernel 5.17 or later

Storage: -40~85℃

Operating: 0~60℃
